HENAN UME CABLE CO., LTD. sales@umecable.com 86-186-38615776
Product Details
Certification: ISO9001, CE, SGS TUV
Payment & Shipping Terms
Model NO.: |
High Temperature Wire AFR-250 |
Material Shape: |
Round Wire |
Range Of Application: |
Overhead |
Brand: |
UME |
Third Party Inspection: |
Accepted |
Sample: |
Free |
Color: |
Customer Specified |
OEM: |
Accepted |
Transport Package: |
Drum |
Specification: |
High Temperature Wire AFR-250 |
Trademark: |
UME |
Origin: |
China |
HS Code: |
7614900000 |
Supply Ability: |
500, 000km Per Month |
Type: |
Insulated |
Conductor Type: |
Flexible |
Application: |
Overhead, Underground |
Conductor Material: |
Silver Plated Copper |
Sheath Material: |
None |
Insulation Material: |
PTFE |
Samples: |
US$ 1/Piece 1 Piece(Min.Order) | Request Samp |
Model NO.: |
High Temperature Wire AFR-250 |
Material Shape: |
Round Wire |
Range Of Application: |
Overhead |
Brand: |
UME |
Third Party Inspection: |
Accepted |
Sample: |
Free |
Color: |
Customer Specified |
OEM: |
Accepted |
Transport Package: |
Drum |
Specification: |
High Temperature Wire AFR-250 |
Trademark: |
UME |
Origin: |
China |
HS Code: |
7614900000 |
Supply Ability: |
500, 000km Per Month |
Type: |
Insulated |
Conductor Type: |
Flexible |
Application: |
Overhead, Underground |
Conductor Material: |
Silver Plated Copper |
Sheath Material: |
None |
Insulation Material: |
PTFE |
Samples: |
US$ 1/Piece 1 Piece(Min.Order) | Request Samp |
ONE-STOP SOLUTIONS FOR WIRES&CABLES - HENAN UME CABLE CO., LTD
Over 30 years of Wires and Cables manufacture experience and Export to over 50 countries.
1. Applications
PTFE insulated high temperature wire AFR-250 is widely used in industrial and mining enterprises such as metallurgy, petroleum, chemical and power plants, and is used as a connecting line for various electrical appliances, instruments and automatic devices under high temperature conditions and harsh environments.
2. Construction
Rated Voltage: 125V, 300V, 600V
Working temperature: -60ºC ~ +250ºC, short-term temperature can be 350ºC.
Conductor: bare copper stranded wire, silver plated copper stranded wire, nickel plated copper stranded wire.
Insulation: PTFE film (polytetrafluoroethylene film wrapped insulation).
| Nominal cross | Conductor structure | Insulation | Average outer diameter (mm) | Conductor DC resistance | Package length (m) |
| section (mm2) | number / wire diameter (mm) | thickness (mm) | at 20 °C (Ω/km) | ||
| 0.035 | 7 × 0.08 | 0.2 | 0.6 | 525 | 500 |
| 0.05 | 7 × 0.10 | 0.2 | 0.7 | 330 | 500 |
| 0.08 | 7 × 0.12 | 0.22 | 0.8 | 227 | 500 |
| 0.12 | 7 × 0.15 | 0.25 | 0.95 | 150 | 500 |
| 0.14 | 7 × 0.16 | 0.17 | 0.82 | 126 | 500 |
| 0.2 | 7 × 0.20 | 0.3 | 1.2 | 83.5 | 500 |
| 0.35 | 19 × 0.16 | 0.3 | 1.4 | 49.5 | 500 |
| 0.5 | 19 × 0.18 | 0.3 | 1.6 | 36 | 200 |
| 0.75 | 19 × 0.23 | 0.35 | 1.85 | 22.7 | 200 |
| 1 × 0.97 | 0.26 | 1.49 | 22.7 | 200 | |
| 1 | 19 × 0.26 | 0.35 | 2 | 19 | 200 |
| 1.2 | 19 × 0.28 | 0.35 | 2.1 | 15.3 | 200 |
| 1.5 | 19 × 0.32 | 0.4 | 2.4 | 11.7 | 200 |
| 2 | 19 × 0.37 | 0.4 | 2.65 | 9.45 | 200 |
| 2.5 | 19 × 0.41 | 0.5 | 3.1 | 6.86 | 100 |
| 4 | 37 × 0.37 | 0.5 | 3.6 | 4.51 | 100 |
| 6 | 37 × 0.45 | 0.5 | 4.2 | 3.05 | 100 |
| 8 | 133 × 0.28 | 0.5 | 5.2 | 2.16 | 100 |
| 10 | 133 × 0.32 | 0.5 | 5.8 | 1.68 | 100 |
| 16 | 133 × 0.39 | 0.6 | 7 | 1.13 | 100 |
| 20 | 133 × 0.45 | 0.6 | 8 | 0.886 | 100 |
| 25 | 196 × 0.40 | 0.6 | 8.8 | 0.734 | 100 |
| 35 | 494 × 0.30 | 0.7 | 10.4 | 0.511 | 100 |
| 50 | 396 × 0.40 | 0.8 | 12.2 | 0.358 | 100 |
| 70 | 551 × 0.40 | 1 | 14.6 | 0.27 | 100 |
| 95 | 760 × 0.40 | 1.2 | 17.2 | 0.21 | 100 |
HENAN UME CABLE CO., LTD has a strict quality control policy in every step from the order to After-sales service!
Production:
Q1: Are you a manufacturer?
Yes, we are the manufacturer.
Q2: What are your main products?
Our products range as follows:
1. Electrical wire/PVC Building Wires.
2. PVC/XLPE insulated Power Cables up to 110kv.
3. Overhead Aerial Bundle Cable/ABC Cables.
4. Bare Conductors, like AAC, AAAC, ACSR, ACAR, ASCR/AW, and so on.
5. Steel wire/strand-like EHS, GSW and ACS(Aluminum Clad Steel), CCS(Copper Clad Steel).
6. Rubber Cables, Mining Cables, Welding Cable, and Control Cables.
7. Concentric Cables with Copper/Aluminum/Aluminum Alloy 8000s' Conductor.
Q3: Do you provide samples? Is it free or extra?
Yes, we could offer the samples for free
Q4: Is the quality of your products guaranteed?
We have passed ISO9001, ISO14001, ISO45001, and all our products have CE certificates.
Q5: Which markets do you involve mainly in?
Our products have been exported mainly to Africa, the Middle East, Southeast Asia, South America, Central America, North America, Europe, Australia, etc.
Q6: What is your payment term?
T/T or L/C
Q7: What about the delivery time?
Generally, it is 3-7days if the goods are in stock. Or it is 7-30days if the goods are not in stock, it is according to quantity.
